OVERVIEW
Convert your wood-burning fireplace to gas, for a new standard of warmth, beauty, safety and convenience.
This Kingsman IDV26 Direct Vent Insert is a great option. With an efficiency rating of 67%, variable speed blower, and dual burner, this fireplace insert could be a high-performing upgrade to any existing wood-burning fireplace. These vent inserts are often installed in any fireplace that exceeds 29.5" wide, 14.125" deep, and 19.5" tall. This insert also includes an adjustable thermostat that permits you to manage the temperature, and therefore the high BTU output allows you to supplement or replace your existing home heating system.
Inserts are complete units that fit into existing wood-burning fireplaces. They require no additions such as glass doors or screens and contains a combustion chamber with gas logs.
Uses a dual vent system, generally two 3" flex gas lines, one pipe is for exhaust, while the other pipe brings in outside air for combustion. the look of those inserts allows for a totally sealed system that doesn't compromise the within air quality of your home.
Kingsman IDV26 Clean View Direct Vent Gas Fireplace Insert with Media provides a premium gas fireplace insert for your home. This insert features heavy-duty steel construction to make sure long-term durability, while ceramic heat-radiating glass offers an impressive view of the firebox. A dual burner with glowing embers offers a realistic flame presentation, while a high-quality ignition allows for easy, safe, and effective ignition of your fire whenever. For added comfort, a heat-activated blower with variable speed control offers increased heat circulation for simpler warming capability.
This unit offers an impressive amount of customization to satisfy the requirements of your installation. choose between propane or natural gas options, add an optional liner, choose between manual or intermittent pilot ignitions and benefit from one of the quality front options to match your tastes. you'll also select from a split oak log set for a traditional appearance or a more contemporary bronze fire glass burner as your project requires.
STANDARD FEATURES
- Color: Black
- On/Off Rocker switch
- 65.3% effencicy rating
- Matchless Piezo Ignition
- Heat radiating ceramic glass
- Dual Burner with glowing embers
- Heat activated blower with variable speed control
- Product Dimensions: 32 3/4" W x 21 1/4" H x 15 7/8" D
- Able to be equipped with a full line of remotes and wall switches
- Includes safety barrier screens to prevent accidental contact with hot glass
- Able to utilize either a detailed split oak log set or contemporary glass media
- Reliable standing pilot valve system ensures ready operation during power outages
- Fireplace insert with dual burners, glowing embers, and variable speed blower assembly
- Able to be used with gas control components pivoted in or out (must use correct surround for each configuration)
- Millivolt valve system allows operation during power failure with adjustable flame control
*Venting Requirements: This unit requires venting pipe with an inner diameter of 3 Inches. Please see the Venting Components section on this page if available for venting pipe that must be used with this unit.
PRODUCT SPECIFICATION
| Model |
IDV26N/NE/NE2 |
IDV26LP/LPE/PE2 |
| Fuel | Natural | Propane |
| Flue | Top | Top |
| Gas Control | Millivolt / IPI | Millivolt / IPI |
| Input Max. | 30,000 BTU |
30,000 BTU |
| Input Min. | 21,000 BTU |
25,000 BTU |
| FE (p.4.1-02)% | 65.25% / 67.37% |
66.30% / 68.30% |
|
Flue Sizes |
3/3" |
3/3" |
|
Glass Size |
27 1/2"W x 17 1/4" H |
35 5/8" W x 29 9/32"H |
|
Glass Type |
Ceramic | Ceramic |
|
Size (WxHxD) |
28"W x 19 1/2"H x 14 1/4" D |
28"W x 19 1/2"H x 14 1/4" D |
|
Viewing Area |
25 1/2"W x 15 1/4"H |
25 1/2"W x 15 1/4"H |
|
Venting |
3/3" Flex |
3/3" Flex |
|
Electronic Ignition |
Yes | Yes |
| Certification | Heater | Heater |
|
Bedroom Approved |
Yes | Yes |
INCLUDES
- Dual Burner with Glowing Embers
- Ceramic Glass
- Variable Speed with Thermostat Controlled Blower
- Safety Screen
CA Residents: See Prop 65 WARNING
OPTIONS & ACCESSORIES
Click to see Log Set or Glass Support Platform (Required to Complete)
Log Set
 |
Fiber Split Oak Log Set (LOGF27)
|
Glass Support Platform
 |
Glass Support Platform with Bronze Decorative Glass (RSP10)
|
Click to see Conversion Kit
Conversion Kit
 |
Conversion Kit to Propane Millivolt (26IDV-CKLP)
Conversion Kit to Natural Gas Millivolt (26IDV-CKNG)
Conversion Kit to Propane Proflame 1 (26IDV-CKLPI)
Conversion Kit to Natural Gas Proflame 1 (26IDV-CKNGI)
Conversion Kit to Propane Proflame 2 (26IDV-CKLP2)
Conversion Kit to Natural Gas Proflame 2 (26IDV-CKNG2)
|
Click to see Clean View Kit (Required to Complete)
Clean View Kit
 |
1 3/4" Deep Clean View Slim Front (I26CV1BL)
|
|
3 1/2" Deep Clean View Slim Front (I26CV3BL)
|
 |
Clean View Slim Picture Frame Front (I26CVPF1BL)
|
 |
Wide Clean View Front (I26CV2BL)
|
 |
Wide Clean View Picture Frame Front (I26CVPF2BL)
|
Click to see Surrounds
Surrounds
 |
Slim Surround (I26S1BL)
|
|
Universal Surround (I26SUBL)
|
|
Slim Picture Frame Surround (I26SPF1BL)
|
Click to see Riser For Surrounds
Riser For Surrounds
|
Riser For I33S4028B Surround (I33R40)
Riser For I33S4430B Surround (I33R44)
|
Click to see Liner Kit
Liner Kit
 |
3 Piece Refractory Liner (IDV26RL)
|
 |
3 Piece Porcelain Reflective Panel Liner (IDV26PRL)
|
Click to see Mantel Clearance Shield
Mantel Clearance Shield
 |
Mantel Clearance Shield (I33CS)
|
Click to see Log Bits Kit
Log Bits Kit
 |
Four Piece Log Bits Kit (VLBIT4)
|
|
Six Piece Log Bits Kit (VLBIT6)
|
Click to see Thermostat
Thermostat
 |
Wall Mount Thermostat- For Millivolt Units (Z2MT)
Programmable Digital Wall Mount Thermostat- For Millivolt Units (Z80PT)
|
Click to see Remote Control
Remote Control
 |
On/Off Remote Control for Millivolt/IPI Units (GFRC)
|
 |
Thermostat Remote Control Millivolt/IPI Units (GTRC, EGTRC)
|
|
|
Thermostat On/Off modulating for Natural Gas/Propane Millivolt/IPI Units
|
Wire Harness
 |
Extension Wire Harness (1001-P904SI) Kingsman 1001-P904SI 10-Foot Wire Harness for Modulating Remote Installation provides a premium accessory to be used with your fireplace remote system. Featuring a 10-foot length, this kit allows for easy installation of the wiring harness. This component is required for the IDV26 when an optional modulating remote is installed (Kingsman GTMRCN, GTMRCP, EGTMRCN, or EGTMRCP).
|
Click to see venting products
venting
| 3/3" Vertical Vent Termination - IDVVT36 | |
 |
3/3-Inch Vertical Chimney Vent Termination provides a premium installation component to be used with your fireplace |
| Flex Pipe Kit - IDVFK25 | |
 |
Flexible Stove Pipe Kit provides a premium installation component to be used with your fireplace. Kit includes two 3" diameter x 25' liners. |
| Block Off Plate - IDVLCP | |
 |
Block Off Plate for Lower Chase provides a premium installation component to be used with your fireplace and this block off plate is intended to be used with Kingsman's Millivolt Control Collection. |
| 3" Flex Connector - ZDV3FC | |
 |
This chimney vent is provided with a flex connector that measures 3-Inches in diameter. This handy vent won't only keep your living room from being damaged but is additionally flexible enough to keep from being easily damaged itself. |
