Country Stoves Georgetown 230 GL 25" Freestanding Wood Stove
Country Stoves Georgetown 230 GL 25" Freestanding Wood Stove
Choose Pedestal or Legs
Required Accessories
-- Please Select --
No, Thank You
Ash Drawers
Optional Accessories
-- Please Select --
No, Thank You
Louvers
Optional Accessories
-- Please Select --
No, Thank You
Door Trim
Optional Accessories
-- Please Select --
No, Thank You
Blowers
Optional Accessories
-- Please Select --
No, Thank You
Outside Air Kits
Optional Accessories
Common Accessories
Optional Accessories
-- Please Select --
No, Thank You
Couldn't load pickup availability
- Free Shipping on Orders Over $400
- Same-Day Order Processing
- Easy Monthly Installments Starting at 0% APR*
• Text or call 888-992-1556
• Email support@usfireplacestore.com
• Start a live chat
Our team is available to serve you 8:00 AM - 11:59 PM ET, 7 days a week.
The Georgetown 230 GL freestanding wood stove offers a more efficient approach to home heating, utilizing our TFT (Thermal Fin Technology) to add more heat to your home.
What's Included
- 25" Wood Stove
- Ceramic Glass
- Interior Brick and Baffle
- Air Wash System
Not Included (Sold Separately)
- Leg/Pedestal (Required to complete)
- Ash Drawer
- Louver
- Door Trim
- Blower
- Outside Air Kits
- Spray Paint
Features
Main Features
- Increased Efficiency – Baffle design helps deflect heat down into the firebox resulting in high efficiency.
- Less Maintenance – Airwash system allows primary combustion air to enter the firebox and keep the glass clean.
-
Quality Construction – Heavy-gauge steel ensures dependable operation.
-
More Heat – TFT (Thermal Fin Technology) provides 32% more surface area than standard stove designs.
-
Increased Comfort – Optional 700-CFM variable-speed blower that helps heat larger spaces.
- Fuel Savings – Secondary combustion system extracts more heat out of every log.
Additional Features
- Thermal Fin heat exchanger creates 32% more surface area than a standard stove design resulting in more heat entering the room.
- Air-boost timer automatically adjusts the air intake control making startup and reloading easier.
- Tall opening provides and expansive view of the burning fire.
- Ceramic glass for extra strength and optimum heat transfer.
- Unique, integral air wash system keeps the glass clean and clear for a wide-open view of the fire.
- Precision-cut, heavy-gauge steel provides dependable,
long-lasting operation. - High-density firebrick retains heat longer, resulting in increased efficiency.
- One-touch control ensures easy operation and comfort.
- EPA-certified and Washington State-approved for clean and
efficient operation.
Specifications
| Material Number | F5028 |
| Model Number | 230GT |
| Collection | Lodge Collection |
| Firebox | 2.3 cu. ft. |
| Maximum Burn Time | 8 hours |
| Efficiency | 80% |
| Heating Capacity | 1200-2200 sq. ft. |
| Maximum BTU | 76,000 per hour |
| Log Length | 18" Log - North to South Loading |
| Stove Type | Wood Burning |
| Vent Type | Vented |
| Vent Size | 6" |
| Top/Rear Vent | Top |
| Front/Top Load | Front |
| Color | Black |
| Configuration | Freestanding |
| Weight | 339 lbs |
Product Dimensions
| Width | 25-1/8" |
| Height (Lakeview Legs) | 32-13/16" |
| Height (Coastal Legs) | 32-1/2" |
| Height (Olympics Legs) | 33-1/2" |
| Height (Pedestal) | 35" |
| Depth | 26-5/8" |
| Stovepipe Diameter | 6" |
Technical Drawings & Dimensions
|
| US Single-Wall Connector |
US Double-Wall Connector |
Canada Single-Wall Connector |
Canada Double-Wall Connector |
|
| D**= Flue Collar to Back Wall | 16" | 10" | 16" | 10" |
| N**= Flue Collar to Side Wall | 22" | 20" | 22" | 20" |
| G**= Flue Collar to Wall | 16" | 15" | 16" | 15" |
|
| E = Back of Stove | 0" | 0" | 8" | 8" |
| F† =Stove Corner to Wall | 5-11/16" | 4-11/16" | 5-11/16" | 4-11/16" |
| H = Pad Depth Minimum | 38-5/8" | 38-5/8" | 49" | 47" |
| I = Pad Depth to Back Wall | 51" | 45" | 51" | 45" |
| J = Pad Width Minimum | 33" | 33" | 41-1/8" | 41-1/8" |
| K = Front of Stove | 16" | 16" | 18" | 18" |
| L = Measured from Door Opening |
8" | 8" | 12" | 12" |
| M = Measured to Sides of Unit |
4" | 4" | 8" | 8" |
| T = Pad Depth to Corner | 58-7/8" | 57-1/2" | 58-7/8" | 57-1/2" |
|
| X = Minimum Width | 52" |
| Y = Maximum Depth | 48" |
| Z = Minimum Height | 72" |
IMPORTANT NOTES:
As with any heating appliance, fireplace or stove, this appliance is extremely hot during operation. Read and understand all operating instructions before using this appliance. For further information, consult your dealer. Actual performance may vary depending upon home design and insulation, ceiling heights, climate, condition and type of wood used, appliance location, burn rate, accessories chosen, chimney installation and how the appliance is operated. Grandview 230 approved for mobile home use. Diagrams, illustrations and photographs are not to scale—consult installation instructions. Product designs, materials, dimensions, specifications, colors and prices are subject to change or discontinuance without notice.
F†= Measured from corner of stove heat shield.
*Square-feet heating capacities and burn times are approximations only. Actual performance may vary depending upon home design and insulation, ceiling heights, climate, condition and type of wood used, appliance location, burn rate, accessories chosen, chimney installation and how the appliance is operated.
**Clearances to flue are from the stove flue collar to combustibles.
***Depending on the type of wood being burned and the amount of heat required.
Warranty
 |
Limited Lifetime Warranty |
