FOR 50-INCH TVs AND SMALLER. Manual swivel fully rotates for the best view. Pop up motorized lift has 28 inches of travel. 3 remotes (wired & wireless RF and IR). Optional rolling base cart adds easy TV mobility.

Expand your TV viewing area with the revolutionary SRV Pro Swivel motorized TV lift. Manually rotate your TV for a full 360-degree turn. With its slim 7-inch depth, the SRV Pro Swivel for 50-inch and smaller flat screens is ideal for pop up installation in a cabinet or RV entertainment console. The advanced A/V technology includes an IR remote and sensor for easy automation.

What's Included

• Touchstone SRV 2800 Pro 360 Swivel
• Wired and Wireless RF and IR remotes
• Flat Top Mount Lid


Not Included

• Rolling Cart
• TV


Features

Alexa® & Google Home® Compatible: You can control your TV lift and memory heights direct from our app or via Alexa & Google Home voice commands.

IR Remote For Easy Pairing With Universal Remotes: The IR remote allows you to pair the SRV TV Lift Mechanism with a third-party universal remote, so you can control your TV and lift mechanism with the same remote control.

Includes Flat Top Mount For Easy Flush Lid: The flat top mount makes it easy to attach a lid for a clean, flush mount installation. Easily attach a matching wood or countertop to the flat top mount for a seamless custom-built cabinet with a hidden TV inside. The included flat top lid mount is 17 3/4 x 4 5/16 inches.

Unique "C" Bracket For Perfect Height: The SRV Pro Swivel TV Lift includes Touchstone’s unique “C” bracket for effortless flat-screen TV height adjustment. The “C” bracket gives you an extra 5 inches of additional height adjustment between the top of the lift and the counter or cabinet top. The wired remote has a visual display so you know precisely how high the lift is raised.

Extra Protection with Soft Start/Stop and Safety Stop: The soft start and stop feature ensures smooth operation as the lift raises or lowers. The safety stop automatically reverses direction when a change in force is detected during the lifting or lowering process to protect users and equipment.

Smooth Operation, Built to Last: The heavy-duty 1.5mm steel SRV Pro Swivel TV Lift with a 24v motor lifts up to 120 lb. The SRV TV Lift includes a 5-year worry-free product warranty - the best warranty offered in this price range, compared to competitors.

Designed For 50-inch TVs and Smaller: The SRV Pro Swivel measures 27 5/8 inches H x 7 inches W x 7 inches D (including the brackets that connect to the back of the TV) and lifts to a full height of 55 5/8 inches in seconds with a lift capacity of 120 pounds. Designed to fit flat-screen televisions and monitors up to 50 inches (diagonal measurement).

Universal Quick Connect System: The SRV Pro TV Lift includes Touchstone's Universal Quick Connect system. This universal hardware kit makes it easy to install any flat-screen TV in minutes. The Touchstone Universal Quick Connect System includes compatible bolts and machine screws to fit most TV brands and models. With the right hardware for your TV, the SRV Pro TV mounting bracket securely locks your TV in place.

Optional Rolling Cart Base Adds Mobility: The SRV Rolling Cart option adds a rolling cart base to the SRV Pro TV lift, creating a movable and adjustable TV stand for conference rooms, classrooms, and offices. For outdoor entertainment, the rolling cart base makes it easy to wheel your TV outside temporarily. The sturdy heavy-duty 1.5mm steel base includes four 360-degree swivel locking wheels and a digital display wired remote, which is a handy alternative to the remote control.

How the SRV Pro Swivel Compares to the Valueline TV Lift: Available exclusively at Amazon, the Touchstone Valueline 30009 TV Lift offers many of the same features as the SRV Pro Swivel 32820. The SRV series adds advanced technology including IR technology and a longer 5-year warranty.

Highlights

• Full 360-degree manual swivel
• Alexa® & Google Home® compatible
• Use our app to control the lift from your phone via Smart Wi-Fi connection
• Holds up to 120 lb.
• Fits most 50-in. TVs and smaller (diagonal measure)
• Soft start and stop for smooth operation
• Safety stop and reverse for when the lift is running up or down to prevent damage or injury
• Includes wired and wireless RF and IR remotes
• 28 inches of vertical travel
• Add the optional Rolling Cart base with wheels for a mobile rolling TV solution
• Lift raises to the full height of 55 5/8 inches
• Fully depressed measures 27 5/8 inches H x 7 inches W x 7 inches D (including TV mount brackets, does not include TV depth)
• Durable Steel Construction with 24 V Motor makes operation quiet and reliable
• Universal Quick Connect system for mounting TV to lift is easy to use and install
• Hardware kit includes all necessary bolts and screws and is compatible with most flat panel TVs in the market today
• Includes wireless RF and IR remote control and a wired handset control
• Supports TVs with VESA mounting patterns up to 400mm wide by 400mm high
• Safety stop while raising and lowering
• Soft start and stop
• Lift not designed for drop-down use

Specifications

Dimensions

Warranty

STANDARD 5-YEAR WARRANTY

Documents & Files

• SRV TV Lift Owners Manual
• SRV Wifi TV Lift Setup Manual
• 32820 SRV 28" PRO Degree Swivel Dimensional Drawing
