ESF.2.B.XL12
With EcoSmart's clean-burning bio ethanol burner you can create a unique atmosphere with superior comfort & design. An ethanol burner gives your imagination the freedom to complement any living space. From fabulous foundations, you enjoy freedom to build beyond the boundaries.
Creating distinctive social settings that are welcoming and feel like ‘home’ is a vital trend across myriad architectural environments - from commercial to hospitality to residential.
Because bioethanol is a clean-burning fuel source you don’t need a flue or chimney at all. This means that you can create a beautiful fireplace feature with ease. The linear features and absolute versatility of the XL1200 burner lends itself to the creation of stunning architectural masterpieces.
Give your traditional fireplace a new and improved look by using this burner as a fireplace insert. Designers can also use it to create a new and unique fire feature. Or, create the fireplace of your dreams, the possibilities are endless.
|
|
2.6 Gal [10 L] |
|
Heats on Average |
700ft2 [65m2] |
|
Minimal Room |
4061ft3 [115m3] |
|
Thermal Output |
17 MJ/h - 15290 BTU/h - 4.5 kW |
|
Burn Time |
9-14h |
*Please Note: "These values are indicative only and may vary depending on the model purchased, installation environment, and the composition of the e-NRG bioethanol sourced in each country."
This burner is also available in other Models:
What's Included: Bioethanol Burner, 1.25 Gallon Jerry Can, Bottle Adapter, Lighting Rod, Refillable Butane Lighter, and Baffles
*Note: "e-NRG Bioethanol Fuel for the burner is sold separately."
|
LIGHTINING ROD This operational accessory enables you to safely adjust the slider position of the Burner at any time. It is also used for the ignition and extinguishing procedures. |
 |
JERRY CAN 1.25 GAL Safety features include automatic stop flow, fast flow rate, locking thumb button control, and self-venting system. |
 |
BOTTLE ADAPTOR The adaptor connects the safety spout from the Jerry Can straight onto the e-NRG bottle making fuelling the fire quicker and easier. |
 |
BUTANE Use this high quality butane gas to refill your EcoSmart Fire Lighter. |
 |
FIRE LIGHTER This refillable butane lighter supports the safe ignition of the lighting rod. The length of the lighter further enhances the management of the lighting process. |
 |
XL BAFFLES XL Baffles are used to regulate and further stabilise the flame increasing fuel efficiency of the burner. |
Easily integrated into bespoke settings – from specially-made cabinetry, media units, walls, floating timber to stone benches and pillars.
Diverse range of materials can be used in your bespoke fire – think concrete and hard timber benches, marble recesses, stacked stone walls, stainless steel – even metal barrels cut in half!
Purpose-designed baffle inserts allow you to regulate and further stabilise the flame.
e-NRG bioethanol produces a beautiful orange flame from start to finish without producing by-products such as smoke, soot or ash.
Awarded the 2009 Hearth & Home Vesta Award (USA).
Easily installed as a standalone ethanol burner in tailored setting or in conjunction with a zero-clearance Flex Fireplace Insert.
EcoSmart collection has been thoroughly tested against a number of global standards and are UL Listed in the USA, Certified for EU and UK in accordance with EN16647, and satisfy the ACCC Safety Mandate for Australia.
UL Listed
|
Dimensions |
47.2" L x 7.7" W x 4.4" D |
|---|---|
| Weight |
34.61lb [15.70kg] |
| Warranty |
|
|
Front View |
 |
|---|---|
| Top View |
|
| Side View |  |
CA Residents: See Prop 65 WARNING.
*Note: "Read the manual carefully before operating the burner. Physical model dimensions should be verified against cut out dimensions BEFORE installation begins to confirm tolerances align."
 |
e-NRG is the highest quality bioethanol fuel available Formulated for use in ventless bioethanol fireplaces, e-NRG is the cleanest, most efficient liquid ethanol fuel on the market and produces the best flame each and every time. |
 |
EcoSmart Fire Plasma Fire Screen is a flat panel of glass provides stability to the flame. The Plasma Fire Screen features two handles positioned either side. The Plasma is supported by simple stainless steel feet that are clamped to the base of the at pane of glass, elevating the screen as if oating while providing enhanced stability. In addition to adding style to your fireplace, it also serves as a safety barrier for the flames and protects the flames from being blown by the wind. |
 |
The Twin Feet Fixings system was created to improve safety around open fireplaces. Designed to lock a glass fire screen into position, these stainless steel feet provide permanent stability, and at the same time allow for easy removal for refueling and maintenance. This optional accessory is compatible with 8mm thick toughened glass. Its design ensures safety, the glass it locks in place will not be easily knocked down by children and pets. |
 |
The Black Glass Charcoal is made from high-quality tempered glass and has been designed to withstand harsh weather and temperatures of up to 1300ºF/700ºC without ever cracking, or losing its colour or shape. Black Glass Charcoal does not emit any toxic fumes, smoke, or ash so it is extremely easy to maintain and clean. Make sure not to put fire glass directly on top of the burner and in places that can interfere with the burner's operation. One bag is good for 0.69ft3 |
Volume Capacity
