Mad Design Group

ESF.2.B.XL5

EcoSmart Fire 20" Stainless Steel XL500 Ethanol Fireplace Burner by Mad Design Group

Color: Stainless Steel


Estimated Arrival: Between and . (To All Contiguous States)


✔ Same-Day Order Processing
✔ Free Returns
✔ No Restocking Fees
✔ Financing Options Available

Text or call 888-992-1556, start live chat, or email support@usfireplacestore.com with any questions. Our team is available to serve you 8:00 AM - 11:59 PM ET, 7 days a week.

With EcoSmart's clean-burning bio ethanol burner you can create a unique atmosphere with superior comfort & design. An ethanol burner gives your imagination the freedom to complement any living space. From fabulous foundations, you enjoy freedom to build beyond the boundaries.

The baby of the XL Series, the XL500 may be compact in size, but this 5L ethanol burner effectively delivers a beautifully long, lasting flame. Like the other models within the XL Series, this fire can be easily integrated into a horizontal, tailor-made setting. Whether you just use the burner by itself or as part of a Flex firebox insert, you have an amazing design tool to achieve your vision.

XL500 ethanol burner can be installed, anywhere indoor or outdoor. Give your traditional fireplace a new and improved look by using this burner as a fireplace insert. Designers can also use it to create a new and unique fire feature. Or, create the fireplace of your dreams, the possibilities are endless.

FUEL EFFICIENCY:

Volume Capacity

 1.3 Gal [5 L]

Heats on Average

431ft2 [40m2]

Minimal Room

2825ft3 [80m3]

Thermal Output

12 MJ/h - 11430 BTU/h - 3.4 kW

Burn Time

10-13h

*Please Note: "These values are indicative only and may vary depending on the model purchased, installation environment, and the composition of the e-NRG bioethanol sourced in each country."

This burner is also available in other Models:

What's Included: Bioethanol Burner, 1.25 Gallon Jerry Can, Bottle Adapter, Lighting Rod, Refillable Butane Lighter, and Baffles

*Note: "e-NRG Bioethanol Fuel for the burner is sold separately."

Click to see Included Accessories




LIGHTINING ROD

This operational accessory enables you to safely adjust the slider position of the Burner at any time. It is also used for the ignition and extinguishing procedures.

JERRY CAN 1.25 GAL

Safety features include automatic stop flow, fast flow rate, locking thumb button control, and self-venting system.

BOTTLE ADAPTOR

The adaptor connects the safety spout from the Jerry Can straight onto the e-NRG bottle making fuelling the fire quicker and easier.

BUTANE

Use this high quality butane gas to refill your EcoSmart Fire Lighter.

FIRE LIGHTER

This refillable butane lighter supports the safe ignition of the lighting rod. The length of the lighter further enhances the management of the lighting process.

XL BAFFLES

XL Baffles are used to regulate and further stabilise the flame increasing fuel efficiency of the burner.

KEY FEATURES:

Design Versatility

Easily integrated into bespoke settings – from specially-made cabinetry, media units, walls, floating timber to stone benches and pillars.

Myriad Materials

Diverse range of materials can be used in your bespoke fire – think concrete and hard timber benches, marble recesses, stacked stone walls, stainless steel – even metal barrels cut in half!

Flame Regulation

Purpose-designed baffle inserts allow you to regulate and further stabilise the flame.

No Harmful By-products

e-NRG bioethanol produces a beautiful orange flame from start to finish without producing by-products such as smoke, soot or ash.

Award-winning

Awarded the 2009 Hearth & Home Vesta Award (USA).

Standalone or Integrated

Easily installed as a standalone ethanol burner in tailored setting or in conjunction with a zero-clearance Flex Fireplace Insert.

Tested World Wide

EcoSmart collection has been thoroughly tested against a number of global standards and are UL Listed in the USA, Certified for EU and UK in accordance with EN16647, and satisfy the ACCC Safety Mandate for Australia.

STANDARD FEATURES:

  • Available in Stainless Steel or Black Color
  • Vent Free - no chimney no gas or electric lines required
  • 304 Stainless Steel
  • Baffle Inserts Allow Flame Regulation and Promotes Fuel Efficiency
  • Suitable for Indoor and Outdoor Use
  • Adjustable flame
  • Manual Match Lit Ignition
  • UL Listed

SPECIFICATIONS:

Dimensions

19.7" L x 7.7" W x 4.4" D
Weight

14.33lb [6.5kg]

Warranty
  • Stainless steel parts including raw, linished and powder coated: 2 Years from Date of Purchase
  • Mild steel including powder coated and chrome plated, Cement, Glass, Leather, Fabric and MDF (Painted OR Cement Rendered): 1 Year from Date of Purchase

TECHNICAL DRAWINGS:

Front View

Top View



Side View

CA Residents: See Prop 65 WARNING.

DOWNLOADS:

*Note: "Read the manual carefully before operating the burner. Physical model dimensions should be verified against cut out dimensions BEFORE installation begins to confirm tolerances align."

OPTIONS & ACCESSORIES:

Click to see e-NRG Bioethanol

e-NRG is the highest quality bioethanol fuel available

Formulated for use in ventless bioethanol fireplaces, e-NRG is the cleanest, most efficient liquid ethanol fuel on the market and produces the best flame each and every time.



Click to see Plasma Fire Screen

EcoSmart Fire Plasma Fire Screen is a flat panel of glass provides stability to the flame. The Plasma Fire Screen features two handles positioned either side. The Plasma is supported by simple stainless steel feet that are clamped to the base of the at pane of glass, elevating the screen as if oating while providing enhanced stability.

In addition to adding style to your fireplace, it also serves as a safety barrier for the flames and protects the flames from being blown by the wind.



Click to see Twin Feet Fixings

The Twin Feet Fixings system was created to improve safety around open fireplaces. Designed to lock a glass fire screen into position, these stainless steel feet provide permanent stability, and at the same time allow for easy removal for refueling and maintenance.

This optional accessory is compatible with 8mm thick toughened glass. Its design ensures safety, the glass it locks in place will not be easily knocked down by children and pets.



Click to see Black Glass Charcoal

The Black Glass Charcoal is made from high-quality tempered glass and has been designed to withstand harsh weather and temperatures of up to 1300ºF/700ºC without ever cracking, or losing its colour or shape. Black Glass Charcoal does not emit any toxic fumes, smoke, or ash so it is extremely easy to maintain and clean.

Make sure not to put fire glass directly on top of the burner and in places that can interfere with the burner's operation. One bag is good for 0.69ft3
