Empire Comfort Systems

DVP20CC30FP

Empire 22" Small Spirit Cast Iron Direct Vent Gas Stove

Ignition Type: Millivolt
Fuel Type: Propane
Finish: Matte Black


Estimated Arrival: Between and . (To All Contiguous States)


✔ Same-Day Order Processing
✔ Free Returns
✔ No Restocking Fees
✔ Financing Options Available

Text or call 888-992-1556, start live chat, or email support@usfireplacestore.com with any questions. Our team is available to serve you 8:00 AM - 11:59 PM ET, 7 days a week.

OVERVIEW

A Direct-Vent system uses two vent pipes. One draws air in from outdoors to support combustion. The other exhausts the by-products of combustion to the outside. The two vent pipes may be concentric (exhaust pipe within a larger diameter intake pipe) or co-linear (separate pipes of about the same size).

Combustion takes place inside a sealed chamber – with a glass front in the
case of a fireplace. Room air circulates around the combustion chamber, often assisted by a blower, to heat the room.

A DV system is often installed along an outside wall to simplify the vent run,
but can also be installed elsewhere in the home and vented through the roof.

Advantages:

  • Good efficiency – 60 to 80%
  • Good heat output with thermal transfer through the glass and air circulation
  • Separates room air from combustion air
  • May be used as primary heat source
  • Can operate with a remote or thermostat
  • Most systems can provide life-saving heat during a winter power outage


Empire Cast Iron Stoves

Direct-Vent Spirit Stoves include Empire’s Slope Glaze Burner system with expanded ember bed for extra glow. Ceramic beads within the burner swirl and tumble the gas to create naturally swirling flames that are indistinguishable from a wood fire. Topped off with the hand-painted ceramic fiber log set and glowing embers, the effect is stunningly realistic and guaranteed to keep you and your guests mesmerized for hours.

Choose from two sizes (20,000 or 27,000 Btu) and three colors – porcelain black, porcelain mahogany, and matte black.

Spirit Stoves are available in two types of ignition.

i) Millivolt (MV)

Empire Cast Iron Stoves are available in two types of ignition – Millivolt (MV) and Intermittent Pilot (IP). The Millivolt system lights a standing pilot with a pushbutton piezo ignitor. Once the standing pilot is lit, the MV system operates with an on/off switch concealed on the back of the stove or with one of Empire’s optional remote control systems.

ii) Intermittent Pilot (IP)

IP systems eliminate the standing pilot for even greater energy savings. Pressing the on/off switch ignites the pilot, which then ignites the main burner. IP systems can also operate with an optional remote control system.

Includes AC Power Adaptor (120VAC) with battery backup (switches to battery during power outage)

Features

  • Upto 20,000 BTUs Slope Glaze Burner
  • Richly detailed casting
  • Decorative cast iron doors (non-operable)
  • Available in three finishes: porcelain black, porcelain mahogany, and matte black
  • Optional side shelf sets available
  • Optional floor pads available
  • Traditional cast iron stove look
  • Your choice of finish and fuel type
  • Compact design with big heat output

Available Models

Includes

  • 4-piece Log Set
  • Fireplace Barrier Screen

Requires

  • 45-Degree Elbow
  • RCK20 Replacement Control Cover required for RVKN or RVKP

Specifications

Model DVP20CC
Dimensions 24 1/8" (H) x 21 1/2" (W) x 16 1/2" (D)
Dimensions with Shelves 24 1/8" (H) x 33 3/4" (W) x 16 1/2" (D)
Venting 4x6 5/8" (Use Black where visible)
Pallet Quantity 4
Gas Type Natural Gas / Propane Gas
Input BTU/HR (KW/H) Max (Propane) 19,500
Input BTU/HR (KW/H) Min (Propane) 13,500
Input BTU/HR (KW/H) Max (Natural Gas) 19,500
Input BTU/HR (KW/H) Min (Natural Gas) 13,500


DOWNLOADS


Clearances

 Top of appliance (ceiling) 36 inches
Rear Wall 2 inches
Side Wall 6 inches
Heater Corners (45° angle) to Wall 4 inches
Floor 0 inches



OPTIONS & ACCESSORIES


Floor Pad Kit

  • Traditional Floor Pad Kit *Requires a Stone Inlay Kit



  • Part Number: CIFPB1
  • Type: Floor Pad Kit
  • Dimensions: ((36 1/2 x 30 13/16 x 7/8)
  • Style: Traditional
  • Optional Floor Pad Kit *(Requires a Stone Inlay Kit)
  • For use with installations of empire cast iron stoves and mantels
  • Corner Floor Pad Kit *Requires a Stone Inlay Kit



  • Part Number: CIFPB1C
  • Type: Floor Pad Kit
  • Dimensions: (42 7/16 x 42 7/16 x 7/8)
  • Optional Floor Pad Kit *(Requires a Stone Inlay Kit)
  • For corner installations of empire cast iron stoves and mantels






Black Porcelain Liner

  • Type: Liner
  • Finish: Black Porcelain
  • Ceramic liners are made by the manufacturer for specific fireplace units.
  • They cannot be cut or they will fall apart





    Cast Iron Stove Left And Right Shelf Kit

    • Type: Stove Shelf Kit
    • Available in three finishes: Matte Black (CSKF), Porcelain Black (CSKB), Porcelain Mahogany (CSKM)
    • Optional accessory
    • Material: Heritage cast iron
    • Set of traditional-style gas stove side shelves
    • Fit compact and medium stoves
    • Quick and straightforward installation





    Automatic Variable Blower

    • Type: Variable Blower
    • Automatic variable speed Blower for Empire heritage cast iron gas stoves
    • Improves efficiency and air distribution
    • Fits with Compact cast iron stove







    GF24 Flexible 24" Stainless Steel Gas Line

    • Flexible Fas Line
    • Finish: Stainless Steel







    Conversion Kit

    • Propane to Natural Gas
    • Natural Gas to Propane



    Click to see Stone Inlays

    Stone American Beauty Marble

    • Type: Inlays Kit
    • Color: American Beauty

    Stone Pearl Marble

    • Type: Inlays Kit
    • Color: Pearl

    Stone Cappuccino Marble

    • Type: Inlays Kit
    • Color: Cappuccino

    Stone Graphite Granite

    • Type: Inlays Kit
    • Color: Graphite Granite


    Click to see Control Options



    FRBC Battery Operated On or Off Remote Control

    • Turn burner OFF and ON using two-button handheld remote (Adjust flame from low to high using knob on the valve)
    • Does not require running wire to the fireplace
    • Requires batteries for the receiver and for the handheld remote
    • Operates during power outages



    FRBTC2 Battery Operated Thermostat Remote Control

    • Type: Remote Control
    • Millivolt Control Options Only
    • Turns heater adjusts Thermostat
    • Battery-operated remote control



    FREC Electric On-Off Remote Control with Battery Transmitter

    • Millivolt Control Options Only
    • Remote control with Battery transmitter for Empire remote-ready appliances
    • Easy and convenient to use
    • The receiver must be plugged in.

    FRBTPS Battery Operated Programmable Touch Screen Remote Control

    • Type: Remote Control
    • Millivolt Control Options Only
    • Programmable and easy to use
    • Battery-operated remote control



    FWS1 Wall Switch On/Off

    • On-Off wall switch for Empire remote-ready appliances

    • Mounts conveniently on wall



    TMV Wall Thermostat Reed Switch

    • Wall thermostat with reed switch for Empire remote-ready appliances
    • Mounts conveniently on wall



    TRW Wall Thermostat Wireless Remote

    • Wall thermostat with wireless remote for Empire remote-ready appliances
    • Thermostat mounts conveniently on wall


    Click to see 45-Degree Termination Kits
    Model Description
    DVK45LP
    • Horizontal 45 Deg Vent Kit (For Propane only)
    • Includes: SD09261B, SD46DVAE45B, SD58DVADC, SD58DVAHSCH, SD58DVAWTEC.
    DVK45NAT
    • Horizontal 45 Deg Vent Kit (For Natural only)
    • Includes: SD46DVA12B, SD46DVADC, SD46DVAE45B, SD46DVAHC, SD46DVAWT3.



    DVKHP45

    • Horizontal Termination Vent Kit
    • Includes: SD46DVA08AB, SD46DVA09, SD46DVA24B, SD46DVADC, SD46DVAE45B, SD46DVAE90B, SD46DVAHC, SD46DVAWT3.



    DVKVP45

    • Horizontal 45 Deg Vent Kit
    • Includes: SD46DVA12B, SD46DVA17TAB, SD46DVADC, SD46DVAE45B, SD46DVAE90B, SD46DVAHC, SD46DVAWT3.


    Click to see Variable Remote (Intermittent Pilot)

    Remote Kit for Natural Gas / Propane

    • Model: RVKN - Natural Gas
    • Model: RVKP - Propane
    • Type: Remote Kit
    • Variable Flame Height Kit

      RCK20 Replacement Control Cover

      • Model: RCK20
      • Type: Control Cover
      • Replacement Control Cover
      • For use with:
      • Remote Kit, Variable Flame Height, Natural Gas (RVKN)
      • Remote Kit, Variable Flame Height, Propane (RVKP)


      Click to see Venting Components



      DuraVent 45-Degree Elbow

      • Finish: Galvanized & Black
      • Use to offset obstructions as needed.
      • Fully unitized, twist-lock construction.
      • Elbows swivel, allowing the lock to remain fully engaged while aligning to the desired direction.
      • The angle will remain fixed at 45°.













      DuraVent 90-Degree Elbow

      • Finish: Galvanized & Black
      • Use to offset obstructions as needed.
      • Fully unitized, twist-lock construction.
      • Elbows swivel, allowing the lock to remain fully engaged while aligning to the desired direction.
      • The angle will remain fixed at 90°.





      DuraVent 17" Elbow Strap

      • Use for supporting vent pipe between offsets.






      DuraVent 6" to 60" Pipe Length

      • Finish: Galvanized & Black
      • Designed for appliances tested and listed for direct vent.
      • Features a fully unitized twist-lock construction in both 4” x 6 5⁄8” and 5” x 8” vent sizes.
      • Use of sealant is optional unless specified by the appliance manufacturer.
      • Black pipe lengths feature exterior laser-welded seams.
      • No beads or hems.
      • To calculate install length, subtract 1 1⁄2” for each joint.






      DuraVent 11" to 17" & 17" to 24" Adjustable Pipe Length

      • Use of sealant is optional unless specified by the appliance manufacturer.
      • Available in black or galvalume exterior (both feature laser-welded outer wall seams).




      DuraVent Wall Strap

      • Use to support vent pipe.
      • Provides 1” clearance.
      • Recommend installing Wall Straps at 4-foot intervals on vertical runs.




      DuraVent Ceiling Firestop

      • Required for multi-story vertical installations on the second floor and any subsequent floors.
      • 4"x 6 5⁄8" style may vary.




      DuraVent Decorative Cover

      • Use as a decorative cover for horizontal (through-wall) installations Fits over the Wall Thimble faceplate.
      • Also used to cover a Ceiling Support Box. Comes with an insulation ring to reduce air infiltration where the pipe slips through the thimble.
      • Painted black.




      DuraVent Attic Insulation Shield

      • Required for installations that pass through an attic to prevent insulation and debris from accumulating near the vent.
      • Provides 1” clearance to combustibles.
      • Includes base w/tube, extension tube, and collar.






      DuraVent Cathedral Ceiling Support Box

      • Use to pass through ceiling and support pipe.
      • May be used on vaulted or flat ceilings.
      • Painted black.
      • Trim and clamp included.






      DuraVent Flat Roof Flashing

      • Use to weatherproof the penetration of vent pipe through the roof.
      • Use on flat roofs, chase enclosures, or masonry chimneys.
      • Storm Collar required.
      • Made of galvalume.




      DuraVent Adjustable Roof Flashing

      • Use to weatherproof the penetration of vent pipe through the roof.
      • Select roof flashing based on pitch of the roof.
      • For pitches of 0/12 - 6/12.
      • Storm Collar required.
      • Made of galvalume.




      DuraVent Steep Roof Flashing

      • Use to weatherproof the penetration of vent pipe through the roof.
      • Storm Collar required.
      • Made of galvalume.




      DuraVent Dead Soft Aluminum Flashings

      • Available in sizes 4”x 6 5⁄8” and 5”x 8”, in 0/12-6/12 (shown) and 7/12-12/12 styles.
      • Made of malleable dead soft aluminum.
      • Use with metal or tile roofs.







      DuraVent Storm Collar

      • Use to maintain a weather-tight resistant seal between the pipe and the flashing.







      DuraVent High-Wind Termination Cap

      • Available in aluminum.
      • Use for vertical terminations only.
      • For vertical terminations only.
      • Provides improved performance in high wind conditions.







      DuraVent Low-Profile Termination Cap

      • Available in aluminum and stainless steel (S).
      • Use for vertical terminations only.
      • Check the appliance manufacturer’s instructions to determine which caps are approved for use with their appliance.







      DuraVent Wall Thimble

      • Use with Square Horizontal Cap only.
      • Provides a complete wall-pass-through and firestop.
      • Refer to the appliance manufacturer’s installation instructions for requirements.
      • May be required in Canada.











      DuraVent Square Horizontal Termination Cap

      • Available in aluminum, stainless steel (S), and copper (C).
      • Use for standard and high-wind through-the-wall termination.
      • Check installation instructions for restrictions on horizontal cap terminations, such as minimum distance from windows and doors.





      DuraVent Round Horizontal Termination Cap

      • Available in aluminum only.
      • Use for through-the-wall termination.
      • Check installation instructions for restrictions on horizontal cap terminations, such as minimum distance from windows and doors.
      • Check with the appliance manufacturer for approval.







      DuraVent 14"/36" Snorkel Termination Cap

      • Use for horizontal through-the-wall termination when a vertical rise is desired in the system to meet the appliance manufacturer's recommended minimum heights.
      • Do not enclose in the wall or install below grade.











      DuraVent Sconce Termination Cap

      • Available in aluminum, stainless steel (S), and copper (C).
      • Use for horizontal through-the-wall termination.
      • Check installation instructions for restrictions on horizontal cap terminations, such as minimum distance from windows and doors.
      • Check with the appliance manufacturer for approval.
      • Patented.







      DuraVent Square Horizontal H2 Termination Cap

      • Available with aluminum shroud.
      • Use for standard and high-wind through-the-wall termination.
      • Provides improved performance in high wind conditions.
      • Adjustable air intake and interchangeable shroud (shroud is included and required for all installations).











      DuraVent High-Wind Sconce Termination Cap

      • Available in aluminum, stainless steel (S), and copper (C).
      • Use for horizontal through-the-wall termination.
      • Provides improved performance in high wind conditions.
      • Check installation instructions for restrictions on horizontal cap terminations, such as minimum distance from windows and doors.





      DuraVent Snorkel H2 Termination Cap

      • Use for horizontal through-the-wall termination when a vertical rise is desired in the system to meet the appliance manufacturer's recommended minimum heights.
      • Features an adjustable air intake and interchangeable shroud (shroud is included and required for all installations).



      WARRANTY

      • 10-year limited warranty on combustion chamber, limited lifetime on glass.
      • All other parts carry a three-year limited warranty.
      • All remote controls carry a one-year limited warranty.

        Search
