SKU:LOF-4808FTAWS-N
Firegear Stainless Steel Linear Flat Pan T Burner Gas Fire Pit Kit w/ AWS Electronic Ignition System
Firegear Stainless Steel Linear Flat Pan T Burner Gas Fire Pit Kit w/ AWS Electronic Ignition System
Flexframe Installation Collar
-- Please Select --
Firegear 3-Piece Pro Series Flexframe Stainless Steel Paver Fire Pit Installation Collar
Firegear 3-Piece Flexframe Stainless Steel Paver Fire Pit Installation Collar
Firegear 2-Piece Flexframe Stainless Steel Paver Fire Pit Installation Collar
No, Thank You
Paver Control Panel Kit
-- Please Select --
Firegear Paver Fire Pit Control Panel Kit for AWS Electronic Ignition System
No, Thank You
Paver Vent Kit
-- Please Select --
Firegear 3.625" x 8" Paver Fire Pit Vent Kit w/ Mounting Plate & Lintel
Firegear 5.625" x 8" Paver Fire Pit Vent Kit w/ Mounting Plate & Lintel
No, Thank You
Glass Media
Lava Rock
Lava Stones
Couldn't load pickup availability
- Free Shipping on Orders Over $300
- Same-Day Order Processing
- Easy Monthly Installments Starting at 0% APR*
• Text or call 888-992-1556
• Email support@usfireplacestore.com
• Start a live chat
Our team is available to serve you 8:00 AM - 11:59 PM ET, 7 days a week.
Firegear Outdoors is the premier provider of outdoor fire products. We specialize in burner systems, outdoor fire features & accessories for the outdoor fire industry.
Overview - AWS Electronic Ignition
Every project is different with its own set of unique challenges. That’s why versatility is paramount when designing and constructing your outdoor project. Firegear Outdoors has developed a new system with the capability to satisfy even the most demanding jobs. This new all weather electronic ignition system will make designing your project easier as well as make installation a breeze.
Features
- Linear stainless steel flat pan
- Stainless steel "T" Burner
- AWS fully electronic ignition - 30VDC (Requires 120Vac) - Assembled (GOE-30VDC) power supply, AWS control panel with On/OFF weatherproof switch.
- Ships as Natural Gas or Propane. (Propane conversion kits are also available and sold separately.)
- Also available in models with TPSI Ignition, and Match Throw Ignition Systems.
Specifications
| Pan Size | Burner Size | BTU | LP Conv. Kit |
| 48” x 8” | 45" | 100,000 | OAS-LPK35 + FG-AWS-PBO |
| 72” x 8” | 69" | 150,000 | OAS-LPK29 + FG-AWS-PBO |
| 84” x 8” | 81" | 175,000 | OAS-LPK26 + FG-AWS-PBO |
| 96” x 8” | 93" | 200,000 | OAS-LPK22 + FG-AWS-PBO |
Options & Accessories
 |
Flexframe Installation Collar
|
 |
Paver Control Panel Kit
|
 |
Paver Vent Kit
|
Media Use Guide & Options
| Pan Size |
Lava Rock |
Glass |
Lava Stones |
| 48” x 8” |
20 lbs. | 50 lbs. |
20 lbs. |
| 72” x 8” |
30 lbs. |
80 lbs. |
30 lbs. |
| 84” x 8” |
40 lbs. | 90 lbs. |
40 lbs. |
| 96” x 8” |
40 lbs. | 100 lbs. | 40 lbs. |
Click to see media options
Media Options
Broken Glass Media
Reflective Glass Media
Lava Rock
Lava Stone
|
Warranty
Residential Application: Lifetime Warranty on construction and manufacturer defects, and stainless steel burners and pans; Five (5) years on gas valve, spark igniter, pilot assemblies, and AWS electronic ignition systems (24VAC, 30 VDC).
Commercial Application: Two (2) years Warranty on construction and manufacturer defects, and stainless steel burners, pans, gas valve, spark igniter, pilot assemblies, and AWS electronic ignition systems (24VAC, 30 VDC).
Downloads
- Product Guide
- Installation and Operating Instructions
- Paver FlexFrame Installation Instructions
- Paver Control Panel Installation Instructions
- Paver Vent Kit Installation Instructions
- Media Use Guide
- Warranty Guide
Safety Information: Check CA Prop 65 Warning for more information.
