Heatscope Heaters 41" Pure+ 3000W Electric Radiant Heater by Mad Design Group

Click to see Included Accessories

MOUNTING PARTS

KEY FEATURES:

All Weather Installation

PURE’s Ingress Protection (IP) rating of IP65 (exceeding the standard IPX5 rating of other brands) enables installation in indoor, semi-enclosed and fully exposed outdoor environments. PURE can withstand general all-weather conditions of wind (dust) and rain. That means it doesn‘t need a protective shield or any additional protection from the elements.

Directional Heating

Easily and accurately change the angle via the swivel joint mount for precise heating. The clean wavelength of light is only absorbed by solid objects, transferring heat directly to a person, table or floor rather than heating the air. Heat won’t simply “blow away” in windy or drafty conditions.

Cleaner, Greener Heat

PURE converts over 90% of input energy directly into radiant heat and operates at a smarter cost per hour. No greenhouse gases or unpleasant odors are emitted, and they don’t require ventilation or a flue.

Instant Heat

At the flick of a switch, PURE reaches maximum output in just 20 seconds producing immediate, comfortable heat when and where you need it.

Curved Glass-Ceramic Screen

The only electric infrared radiant heater worldwide fitted with a convex SCHOTT NEXTREMA® glass front. Spreads warmth evenly across an area while minimizing light emission. Beautifully resolved with black or white colored glass.

Design Aesthetic

Constructed from premium materials and made with meticulous attention to detail - PURE strikes the perfect balance between innovative styling and technical performance. Available in either black or white PURE is an elegant yet powerful heating solution for all environments.

Maximum Heat With Minimum Light

Carbon fiber elements charged with an electric current generate heat but minimal light, creating a softer, super comfortable heat without the harsh light. PURE provides a subtle, low glow, which doesn’t change the lighting effect of a room or the color of objects (including food!).

Simple Maintenance, Ultra Durable

No valves, ignition components or burners to maintain or repair. Aluminum chassis means it won’t discolor or tarnish over time and provides superior design, shape and heat transfer.

Ease Of Use

Single ON/OFF switch, plus two adjustable output levels – 100% and 50%. Can also be integrated with Smart Home Systems – perfect for the connected home.

Easy Installation

Dedicated wall & ceiling mounts (which only need two screws to be securely attached), enable subtle placement anywhere.

Award-Winning Design

Delivers pleasant heat without the distraction. Clean-cut, modern designs and colours easily blend into any decor.

Fast Heating

Noticeable heat within milliseconds and 100% heat within 15-60 seconds.

Weather-Resistant

All models are certified with an IP rating for protection against dust, splash-water, and wind.

No Aggressive Red Light

Produces a very ambient, modest light based on double carbon heating elements.

High Efficiency

Up to 94% of the energy used is turned into ambient heat and transferred directly to nearby people and surfaces for maximum efficiency.

Smart Switch

Operate and sync your heater(s) with your smart device (compatible with Alexa and Google Assistant). *Internet connection and additional accessories required

2-Year Warranty

Our radiant heaters come with an industry leading two-year limited warranty.

STANDARD FEATURES:

• Electric Carbon Radiant Heater for Indoor or Protected Outdoor Use
• Wall or Ceiling Mounted
• Available in Black or White
• Aluminum construction
• Up to 94% efficiency heater
• Precise Directional Heating
• Easy to install

• 3000 Watts
• 10,236 BTUs
• 12.5 Amps
• 220-240 V AC
• UL Listed

TECHNICAL SPECIFICATIONS:

*Please Note: "All values are approximate. Max. temperature increases achievable in enclosed spaces at 16 °C (dependent on the respective installation conditions and mounting height)."

COVERAGE AREA:

*Note: "TThis graphic shows the heating performance of Heatscope Pure 3000W heaters. Please note that the heat output always depends on a wide range of factors."

TECHNICAL DRAWINGS:

Front View
Side View
Top View

CA Residents: See Prop 65 WARNING.

DOWNLOADS:

• Download Installation and Operation Manual
• Download C&I Manual
• Download Specs Sheet
• Download Summary Brochure

OPTIONS & ACCESSORIES:

Click to see Mounting Accessories (Pure Extension Rods)

	100MM Pure Extension Rod - White Extend the reach of your HEATSCOPE® Pure heaters on high ceiling installations with 100mm Extension Rods.
	100MM Pure Extension Rod - Black Extend the reach of your HEATSCOPE® Pure heaters on high ceiling installations with 100mm Extension Rods.
	300MM Pure Extension Rod - White Extend the reach of your HEATSCOPE® Pure heaters on high ceiling installations with 300mm Extension Rods.
	300MM Pure Extension Rod - Black Extend the reach of your HEATSCOPE® Pure heaters on high ceiling installations with 300mm Extension Rods.
	500MM Pure Extension Rod - White Extend the reach of your HEATSCOPE® Pure heaters on high ceiling installations with 500mm Extension Rods.
	500MM Pure Extension Rod - Black Extend the reach of your HEATSCOPE® Pure heaters on high ceiling installations with 500mm Extension Rods.

Click to see SmartBox

	SmartBox - Black Mount this SmartBox control unit between power supply and your HEATSCOPE® Pure heater. Switch your heater ON and OFF, and regulate power level with the included IR Remote.
	SmartBox - White Mount this SmartBox control unit between power supply and your HEATSCOPE® Pure heater. Switch your heater ON and OFF, and regulate power level with the included IR Remote.

Click to see Dual WiFi Smart Switch

This WiFi based 2 gang switch can connect and independently control the operational settings available in your HEATSCOPE® heater. The 2 gang switch offers easy installation and operation, quick WiFi access, and remote control through APP EweLink. It is installed inline between the fuse box and the Heatscope Heater, and it allows the appliance to receive commands via a Smartphone (eWeLink App) including: On & Off scheduling Controlling the appliance heat output: 0% - all elments turned off 50% - one element turned on 100% - two elements turned on *Important: Dual Wi-FI Smart Switch supports Amazon Alexa and Google Assistant

Zigbee Accessories (Use with Dual WiFi Smart Switch Control):

Wireless Switch (remote control) and Motion Sensor require a ZigBee Bridge to operate. You can group up to 32x Heatscope Heaters per bridge controller, but every heater needs its own Dual WiFi Smart Switch.

Click to see Zibgee Bridge

This ZigBee Bridge is the heart of a smart home/space automation setup that enables you to remotely manage a selection of ZigBee devices and sensors. It maximizes efficiency for up to 32 connected sub-devices which are ZigBee-based switches, plugs and security control/ activation sensors. Ideal for large residential and commercial spaces where multiple appliances are installed so you can operate them as a group rather than as independent appliances.

Click to see Zibgee Wireless Switch (*Require the Zigbee Bridge)

This ZigBee Wireless Switch is effectively a mini portable remote control that can be placed strategically for quick and easy operation of your heater. Use the app to set up actions around the home or commercial setting eg a single tap could turn all appliances on LOW, a double tap could turn everything on HIGH then a single tap could turn everything OFF at the same time.

Click to see Zibgee Motion Sensor (*Require the Zigbee Bridge)

This ZigBee Motion Sensor is an extra-handy smart device that can be placed anywhere in your home or commercial space to detect motion and trigger actions. For the home you can set a trigger to turn the HEATSCOPE® appliance OFF if no motion is detected for a specified time. For restaurants you can trigger a bank of HEATSCOPE® heaters (or series of appliances) to switch ON if motion is detected at a zone of tables. This means you can control your heating bills at the same time as delivering comfort and warmth to your visitors and customers and not be wasteful with energy.
