Invicta Nelson 36" Cast Iron Wood Burning Stove


Estimated Arrival: Between and . (To All Contiguous States)


✔ Same-Day Order Processing
✔ Free Returns
✔ No Restocking Fees
✔ Financing Options Available

Text or call 888-992-1556, start live chat, or email support@usfireplacestore.com with any questions. Our team is available to serve you 8:00 AM - 11:59 PM ET, 7 days a week.

Nelson 36" Cast Iron Stoves

The two glass sides of our Nelson stove give a unique character to your home. Cozy evenings await. Settle in on either side of the stove, and listen to the unmistakable sound of the crackling fire as you watch the flames dance.

Pleasant evenings ahead, at each side of the stove, the rhythm of the crackling fire and dance of the flames are now unmissable. Have it set in the middle of a room to create a central fire attraction or as a room divider between two room, this stove will let you have an open space with a totally clear vision all around.
This double sided stove gives a unique character to your home. A double sided modern clean lined slow combustion cast iron wood stove that has amazing proportions and very impressive heat output.

The Invicta Nelson Cast-Iron See-Through Wood Stove features a double sided viewing window, making this stove an excellent choice for inner room installation. The Nelson is ideal for central placement and will easily become the focal of your interior space. Nelson is double sided with double doors.

Features

OPTIMAL POWER
 12 kW
POWER MODULATION
 8 to 18 kW
HEAT VOLUME
 160 - 360 m³
HEATING SURFACE
 65 to 145 m²
EFFICIENCY
 70 %
CO RATE
 0.15 %
CONCENTRATION OF POWDERS
 82 mg/Nm³
PERFORMANCE INDEX
 1,2
COMBUSTILE
 Logs 25, Logs 33, Logs 50 cm
MAXIMUM LENGTH OF THE LOGS (HORIZONTALLY)
80 cm
LOAD
 Two front sides
SMOKE EXHAUST
 Top
DIAMETER OF NOZZLE
 180 mm
DIMENSIONS
H 930 x W 910 x D 480 mm (36.6 x 35.8 x 18.9 in.)
WEIGHT
201 kg
DESIGN
 Contemporain
MATTER
 Cast Iron
COMPLETION
 Anthracite
CERTIFICATION
 EN 13240
GUARANTEE
 5 years


Why this product?

Adjustable secondary air

Secondary air protects the glass against smoke and soot deposits. It ensures combustion of volatile materials. The adjustable secondary air flow can adapt the unit’s operation to high draft conditions.

Clean glass

    The clean glass system slows deposit buildup on the glass. An air supply above the glass creates a protective curtain. The preheated air is propelled along the glass. It triggers combustion of gas and volatile materials, thereby protecting the glass against smoke and soot deposits.

    Double opening

      Unit has two doors. Ideal for separating two rooms to reload the wood from one side to another.

      Double face

      Intermittent

      The unit operates with regular loading of small quantities of wood. This operating method is particularly high-performing and respectful of the environment.

      Origine France Garantie (Made in France Guarantee)

        The Origine France Garantie is the only certification that certifies a product was manufactured in France.

        Technical Elevations

        Optional Accessories

        Stove Bench

          This black sandblasted steel bench is both modern and practical. It has 4 levelers.  Available in two sizes (39 Inches, 63 Inches) , it allows you to install your Preston, Aaron or Réva stove.

           6169-31 DECORATIVE SUPPORT BENCH BLACK 39 W X 17.5 H X 21.5 D 39" Decorative Stove Bench: 39 W X 17.5 H X 21.5 D
          6961-28 DECORATIVE SUPPORT BENCH BLACK 63 W X 17.75 H X 21.5 D 63" Decorative Stove Bench: 63 W X 17.75 H X 21.5 D

          Please Note: Do not connect the stove to any hot air distribution system

          Also Note: This appliance must be installed on a non-combustible protector that extends to the front, sides, and back of the appliance.

          Click to see venting products


          venting products

          4" Length DuraBlack Stovetop Adapter - 7DBK-AD
          Use to adapt DuraBlack stovepipe to appliance flue outlets.
          12" Length DuraBlack Single-Wall Black Pipe - 7DBK-12
          Use for a single-wall connector pipe. Requires 18” clearance to combustibles. Subtract 1 1⁄4” from length to calculate the installed length.
          24" Length DuraBlack Single-Wall Black Pipe - 7DBK-24
          Use for a single-wall connector pipe. Requires 18” clearance to combustibles. Subtract 1 1⁄4” from length to calculate the installed length.
          48" Length DuraBlack Single-Wall Black Pipe - 7DBK-48
          Use for a single-wall connector pipe. Requires 18” clearance to combustibles. Subtract 1 1⁄4” from length to calculate the installed length.
          DuraBlack Slip Connector With Trim - 7DBK-SC
          Used to adapt DuraBlack pipe to 6” - 8” Ceiling Support Box, including DuraTech, and DuraPlus. The Slip connector can also be added to 6” - 8” DuraTech finishing collar.
          45-Degree DuraBlack Elbow - 7DBK-E45
          Offsets obstructions as needed. Elbows angles are now adjustable. Adjustable elbows are manufactured drip-free so creosote travels back to the stove as intended.
          90-Degree DuraBlack Elbow - 7DBK-E90
          Offset obstructions as needed or to orient the stovepipe horizontally through the wall installation. Adjustable elbows are manufactured drip-free so creosote travels back to the stove as intended.
          DVL Double-Wall Black Stovepipe Adapter - 7DVL-AD
          Connects DVL pipe to the appliance flue outlet. Use as a stove adapter.
          6" DVL Double-Wall Adjustable Black Stovepipe - 7DVL-6ADJ
          8” clearance to ceilings, including cathedral ceilings. Use to add length to DVL pipe. 6” pipe adds 2”-5” of length.
          29"-46" DVL Double-Wall Black Stovepipe Telescoping Length - 7DVL-46TA
          Use for a two-piece installation from stove to ceiling support box or finishing collar. No cutting is required.
          40"-68" DVL Double-Wall Black Stovepipe Telescoping Length - 7DVL-68TA
          Use for a two-piece installation from stove to ceiling support box or finishing collar. No cutting is required.
          6" DVL Double-Wall Black Stovepipe - 7DVL-06
          Designed for installation with minimum clearance to combustibles (6” to walls, 8” from top of horizontal run to ceiling). Subtract ¾” for installed length. Constructed with a stainless steel inner wall.
          12" DVL Double-Wall Black Stovepipe - 7DVL-12
          Designed for installation with minimum clearance to combustibles (6” to walls, 8” from top of horizontal run to ceiling). Subtract ¾” for installed length. Constructed with a stainless steel inner wall.
          18" DVL Double-Wall Black Stovepipe - 7DVL-18
          Designed for installation with minimum clearance to combustibles (6” to walls, 8” from top of horizontal run to ceiling). Subtract ¾” for installed length. Constructed with a stainless steel inner wall.
          24" DVL Double-Wall Black Stovepipe - 7DVL-24
          Designed for installation with minimum clearance to combustibles (6” to walls, 8” from top of horizontal run to ceiling). Subtract ¾” for installed length. Constructed with a stainless steel inner wall.
          48" DVL Double-Wall Black Stovepipe - 7DVL-48
          Designed for installation with minimum clearance to combustibles (6” to walls, 8” from top of horizontal run to ceiling). Subtract ¾” for installed length. Constructed with a stainless steel inner wall.
          45-Degree DVL Double-Wall Black Elbow - 7DVL-E45
          8” clearance to ceilings, including cathedral ceilings. Offsets obstructions as needed. Elbows angles are adjustable.
          90-Degree DVL Double-Wall Black Elbow - 7DVL-E90
          Offsets obstructions as needed. Elbows angles are adjustable. Not recommended for rear exit appliances.
          DVL/DuraBlack Chimney Adapter With Trim - 7DVL-ADT
          Use to connect from double-wall DVL to DuraTech, DuraPlus, and DuraLiner for a through-the-wall or ceiling support installation. Provides a strong mechanical connection.
          DBK-DS DuraBlack Damper Section - 7DBK-DS
          Install at, or close to, the stove outlet in-line. 5” pipe section with the damper pre-installed.
          DVL Double-Wall Black Adapter/Damper Section - 7DVL-ADWD
          8” clearance to ceilings, including cathedral ceilings. Connects DVL pipe to the appliance flue outlet. Use as a stove adapter.
          12" DVL Double-Wall Adjustable Black Stovepipe - 7DVL-12ADJ
          Use to add length to DVL pipe. 12” pipe adds 2”-11” of length when used with rigid sections of pipe.
          DBK-TC DuraBlack Trim Collar - 7DBK-TC
          Use as a decorative Trim Collar for DuraBlack connection to the chimney.
          DVL/DuraBlack Chimney Adapter - 7DVL-ADC
          Use to connect from double-wall DVL and/or single-wall DuraBlack to DuraTech, DuraPlus, and DuraLiner for a through-the-wall or ceiling support installation.

          Downloads

          Invicta Nelson stove Catalog

          Invicta Nelson stove Installation And Owners Manual

          Invicta Nelson stove Technical Specification

          Invicta Nelson stove Brochure

          Invicta Nelson stove Comparison Chart
