The ultimate in Zero Clearance Direct Vent Fireplaces for new home construction or renovation, and your best choice for installation anywhere throughout your home.
A gas direct vent fireplace is that the most popular choice by both builders and homeowners for new construction or a remodel. These fireplaces burn efficiently enough to be a heat source but not too efficient to where the fire lacks realism.
This fireplace is hugely customizable. Choose one or all of the many customizable options to create the fireplace that's right for your home. The millivolt valve system doesn't use electricity, instead, it's a standing pilot which allows operation during a power outage with hi-low heat and flame adjustment. the design of this fireplace allows for a totally sealed system that doesn't compromise the air quality of your home.
Choose from a variety of decorative options to create your own distinctive appearance and be assured of complete safety, comfort and long-lasting value. Select from a millivolt or intermittent pilot ignition system. The millivolt valve system does not use electricity but has a standing pilot which allows operation during a power failure with hi-low heat and flame adjustment. The intermittent pilot ignition is electronic and uses an electrode to ignite the pilot. The IPI system ensures the pilot flame extends over the burner for immediate ignition and it conserves energy when the appliance is not in operation.
What's Included
- HBZDV4736 Gas Fireplace
- Dual Burner
- Safety Screen
- Wall Switch
- Tempered Glass
- 4/7" Sloped Flue
- Framing (Louvered)
- SIT Valve with Hi/Lo Adjustment
Not Included (Sold Separately)
- Fiber Split Oak Log Set (Required)
- Grill Kit Or Designer Clean View Kit (Required)
- Fan Kit w/Variable Speed Wall Mount Control
- Thermostats and Remote Controls
- Log Bits (Small Six Piece Kit)
- Brick Or Porcelain Liners
- Gas Conversion Kit
Features
- Tempered glass
- Safety screen barrier
- Zero clearance fireplace
- Your choice of natural gas or propane
- Dual burner with Realistic Flame Pattern
- A flame sensor that constantly monitors the pilot flame
- Millivolt or IPI valve system allows operation during a power failure with Hi/low heat and flame adjustment
Specifications
| Model | HBZDV4736N |
| Fuel | Natural Gas |
| Flue | Top |
| Gas Control | Millivolt |
| Input Max. | 40,000 BTU |
| Input Min. | 27,000 BTU |
| FE (p.4.1-02)% | 60.39% / 61.88% |
| Glass Type | Tempered |
| Venting | 4/7" Venting |
| Certification | Heater |
|
Power Vent |
Yes |
Dimensions
| Width | 47" |
| Height | 43" |
| Depth | 19" |
| Viewing Area Width | 39" |
| Viewing Area Height | 26" |
| Glass Width | 42" |
| Glass Height | 29" |
| Actual Width (CVCK) | 48" |
| Actual Height (CVCK) | 49" |
| Actual Depth (CVCK) | 22" |
| Actual Width (Louvers) | 47" |
| Actual Height (Louvers) | 43" |
| Actual Depth (Louvers) | 19" |
Warranty
- This Limited Lifetime Warranty applies only while the unit remains at the site of the original installation and only if the unit is installed inside the continental United States, Alaska, Hawaii, and Canada.
- The warranty applies only if the unit is installed and operated in accordance with the printed instructions and in compliance with applicable installation and building codes and good trade practices.
