VPS170-AA1
Reznor HVAC has 130 years of experience manufacturing a wide range of industry-leading industrial and commercial HVAC products. Reznor built its reputation by providing reliable, high-quality heating, ventilation and cooling systems.
Since its founding in 1888, Reznor has remained at the forefront of HVAC technology. Reznor is a global leader thanks to its innovative, extended range of gas-fired unit heaters, air handlers, condensers and rooftop units.
Reznor's VPS is a positive-pressure heating system. Units are available with a Calcoat® combustion chamber tube and rolled steel heat exchanger tubes. Reznor radiant heating is among the most environmentally friendly heating solutions on the market, greatly assisting industry and commerce in improving their overall energy performance and making a significant contribution to achieving compliance with the LEED green building rating system.
The VP series of tubular radiant heaters are available in BTUH inputs ranging from 60,000 to 200,000 and in system lengths from 20 to 80 feet (see the following pages for BTUH/system length combinations). Heaters are available for use with natural gas or optional propane gas. Tubular radiant heaters are engineered to provide quiet, reliable, energy-efficient, and comfortable heating for both spot and space applications.
| Model | VPS170 |
| Product Type | Unit Heater |
| Fuel Type | Natural Gas or Propane |
| Installation Type | Ceiling Mount |
| Heating Capacity | 125,000 to 170,000 BTU/H |
| Ignition | Electronic Program Startup with Spark Ignition |
| Gas Connection | 1/2" N.P.T |
| Voltage |
115V/1/60 |
| Wattage | 37,000 to 50,000 |
| Model | Standard | Angled | ||
| Minimum | Recommended | Minimum | Recommended | |
| ft/m | ft/m | ft/m | ft/m | |
| VPS170 | 16/4.9 | 18/5.5 | 14/4.3 |
15/4.6 |
The UDX can be used in many markets including:
Reznor warrants to the original owner-user that this product will be free from defects in material and workmanship. This warranty is limited to twelve (12) months from the date of original installation, whether or not actual use begins on that date, or eighteen (18) months from date of shipment, whichever occurs first.
Safety Information: See CA Prop 65 Warning
