Schwank 33" ElectricSchwank Single Element 1000W Infrared Electric Patio Heater

Schwank 33" ElectricSchwank Single Element 1000W Infrared Electric Patio Heater

Regular price $802.00
Regular price $0.00 Sale price $802.00
Sale Sold out
Color
  • Free Shipping on Orders Over $300
  • Same-Day Order Processing
  • Easy Monthly Installments Starting at 0% APR*
Got a question?
• Text or call 888-992-1556
• Email support@usfireplacestore.com
• Start a live chat

Our team is available to serve you 8:00 AM - 11:59 PM ET, 7 days a week.

ElectricSchwank 33" 1000 W Single Element heater is a sleek and stylish infrared heater that can be wall, ceiling, or flush mounted anywhere you want. Combined with easy to use control options, this heater is perfect for any patio setting. Available in stainless steel and six custom colors.

33" electricSchwank heater can be wall or ceiling mounted. Easy to install indoors or outdoors with the swivel brackets included. For flush mounting, get the optional flush mount frame kit. Get the right amount of heat for your patio. This low power heater is best for residential and indoor installation.

Control options are available to adjust the heating comfort across your patio with the flick of a switch. All controls are available with no cover, weatherproof cover, or weatherproof box models with flush-mount or surface-mount options.

Also Available in other models:

APPLICATIONS:

  • Patios
  • Sports venues
  • Outdoor smoking areas
  • Balcony/terrace
  • Hobby shops
  • Garage/workshop
  • Warehouse facilities

FEATURES:

  • Electric heater for Indoor and Outdoor installations due to low clearance requirements
  • Wall or ceiling mounted, swivel brackets included
  • Stainless Steel construction ensures durability and corrosion resistance.
  • Custom Powder Coating Available in Almond, Beige, Biscuit, Black, Bronze, and White for an additional cost. Custom colors have longer lead times.
  • Minimal Maintenance Cost compared to gas
  • Quartz element for efficient heating
  • Control options are available to adjust the heating comfort across your patio with the flick of a switch
  • Mounting Height: 6' to 8' for efficient heat coverage.
  • Heat Coverage: Approximate 5' x 5'
  • UL Listed
  • Made in the USA

SPECIFICATIONS:

Installation: Wall / Ceiling Mounted
Grade:

Commercial / Residential
Fuel Type: Electric
Material: Stainless Steel
Heater Type: Infrared
Heating Area:

5 ft. x 5 ft.
BTUs:
  • 1000W model: 3,412
Volts: 120
Amps:
  • 1000W model: 8.3
Dimensions: 8.1875" D x 6" H x 33" W
Weight: 12 lbs
Warranty:
  • The Schwank warrants the burner and mantle for a period of three years (3 years).
  • Schwank supply any component part of the heater, excluding any labor, which the Schwank's examination determines to be defective in workmanship or material for a period of one year (1 year) from the date of installation, unless otherwise specified below.


OPTIONS & ACCESSORIES:

Click to see Recessed Mount Frame

Schwank Recessed Mount Frames allow you to seamlessly blend your ElectricSchwank heater with the surrounding area and your décor.  This stainless steel frame is available in three sizes.

Your ElectricSchwank heater will look even better flush mounted on any flat ceiling. Just choose the right frame size for your heater, 33", 39", or 61".



Click to see Simple On/Off Switches Control Options

Single Switch - Flush Mount c/w S/S Wall Plate and Deep Gang Box

Schwank Simple On/Off Switches allow you to turn your electricSchwank heater on or off by flipping a switch. Each heater requires a dedicated switch.

Choose a switch based on where it will be installed and how, in-wall or surface mount. For indoor and outdoor protected areas, a weatherproof cover is not needed.


Single Switch - Flush Mount c/w Weatherproof Cover

Schwank Simple On/Off Switches allow you to turn your electricSchwank heater on or off by flipping a switch. Each heater requires a dedicated switch.

Choose a switch based on where it will be installed and how, in-wall or surface mount. For indoor and outdoor protected areas, a weatherproof cover is not needed.

Single Switch - Surface Mount c/w Weatherproof Gang Box and Cover

Schwank Simple On/Off Switches allow you to turn your electricSchwank heater on or off by flipping a switch. Each heater requires a dedicated switch.

Choose a switch based on where it will be installed and how, in-wall or surface mount. For indoor and outdoor protected areas, a weatherproof cover is not needed.

Dual Switch - Flush Mount c/w S/S Wall Plate and Deep Gang Box

Schwank Simple On/Off Switches allow you to turn your electricSchwank heater on or off by flipping a switch. Each heater requires a dedicated switch.

Choose a switch based on where it will be installed and how, in-wall or surface mount. For indoor and outdoor protected areas, a weatherproof cover is not needed.

Dual Switch - Flush Mount c/w Weatherproof Cover

Schwank Simple On/Off Switches allow you to turn your electricSchwank heater on or off by flipping a switch. Each heater requires a dedicated switch.

Choose a switch based on where it will be installed and how, in-wall or surface mount. For indoor and outdoor protected areas, a weatherproof cover is not needed.

Dual Switch - Surface Mount c/w Weatherproof Gang Box and Cover

Schwank Simple On/Off Switches allow you to turn your electricSchwank heater on or off by flipping a switch. Each heater requires a dedicated switch.

Choose a switch based on where it will be installed and how, in-wall or surface mount. For indoor and outdoor protected areas, a weatherproof cover is not needed.



Click to see Variable Controls

Single Regulator - Flush Mount c/w S/S Wall Plate and Deep Gang Box

Schwank Variable Control for Single Element ElectricSchwank Heaters is a simple and affordable way to control the temperature. Easily adjust the temperature by turning a knob that regulates the voltage supplied to the heater. Each ElectricSchwank heater requires a dedicated variable control regulator

Choose a switch based on where it will be installed and how, in-wall or surface mount. For indoor and outdoor protected areas, a weatherproof cover is not needed.


Single Regulator - Flush Mount c/w Weatherproof Cover

Schwank Variable Control for Single Element ElectricSchwank Heaters is a simple and affordable way to control the temperature. Easily adjust the temperature by turning a knob that regulates the voltage supplied to the heater. Each ElectricSchwank heater requires a dedicated variable control regulator

Choose a switch based on where it will be installed and how, in-wall or surface mount. For indoor and outdoor protected areas, a weatherproof cover is not needed.

Single Regulator - Surface Mount c/w Weatherproof Gang Box and Cover

Schwank Variable Control for Single Element ElectricSchwank Heaters is a simple and affordable way to control the temperature. Easily adjust the temperature by turning a knob that regulates the voltage supplied to the heater. Each ElectricSchwank heater requires a dedicated variable control regulator

Choose a switch based on where it will be installed and how, in-wall or surface mount. For indoor and outdoor protected areas, a weatherproof cover is not needed.

Dual Regulator - Flush Mount c/w S/S Wall Plate and Deep Gang Box

Schwank Variable Control for Single Element ElectricSchwank Heaters is a simple and affordable way to control the temperature. Easily adjust the temperature by turning a knob that regulates the voltage supplied to the heater. Each ElectricSchwank heater requires a dedicated variable control regulator

Choose a switch based on where it will be installed and how, in-wall or surface mount. For indoor and outdoor protected areas, a weatherproof cover is not needed.

Dual Regulator - Flush Mount c/w Weatherproof Cover

Schwank Variable Control for Single Element ElectricSchwank Heaters is a simple and affordable way to control the temperature. Easily adjust the temperature by turning a knob that regulates the voltage supplied to the heater. Each ElectricSchwank heater requires a dedicated variable control regulator

Choose a switch based on where it will be installed and how, in-wall or surface mount. For indoor and outdoor protected areas, a weatherproof cover is not needed.

Dual Regulator - Surface Mount c/w Weatherproof Gang Box and Cover

Schwank Variable Control for Single Element ElectricSchwank Heaters is a simple and affordable way to control the temperature. Easily adjust the temperature by turning a knob that regulates the voltage supplied to the heater. Each ElectricSchwank heater requires a dedicated variable control regulator

Choose a switch based on where it will be installed and how, in-wall or surface mount. For indoor and outdoor protected areas, a weatherproof cover is not needed.



Click to see Solid State Control Options

Zone Analog Controller:

Schwank Zone Analog Controller has the ability to adjust heating intensity. All Controllers are NEMA 12 RATED, and can be exposed to mist, but not direct rain. Each Intensity Control Knob can control a maximum of three relays in the Relay Panel.


Solid State Relay Panel:

The Solid State Relay Panel and Zone Analog Controller (with or without optional timer) work together. All Relay Panels are NEMA 4 RATED, and completely weather resistant.
Maximum of 9,000 watts @ 240V or 8,000 watts @ 208V per relay.



Click to see Home Management Relay Panel
  • Integrate electricSchwank heaters directly into your home management system.
  • All Relay Panels are NEMA 4 RATED, and completely weather resistant.
  • Note: Requires 0-10V DC Signal


Electromechanical Relay Package:

This package includes NEMA 4 rated enclosure kit and appropriate relay depending on the number of heater amp draw.

Click to see Control Panel Enclosure Kit – NEMA 4 RATED

Kit Includes:

  1. 1 x Enclosure – NEMA 4 RATED – JM-4000-XX
  2. 1 x Transformer – 40VA – JL-0776-XX
  3. 1 x Terminal Block – JM-0455-DD

*Note: "Each control panel (enclosure) fits maximum of 2 relays."


Click to see Electromechanical Relays (EMR)



The Electromechanical Relay (EMR) package allows you to install and control your heaters using any 24/120V thermostat or our TC Plus controller.This package includes NEMA 4 rated enclosure kit and appropriate relay depending on the number of heater amp draw.

  • Each relay can handle up to 3 heaters
  • Each control panel (enclosure) fits maximum of 2 relays
